CM-8825FN Digital Coating Thickness Meter 0~1250um / 0~50mil + Built-in F & NF CE Marking Aluminum / Iron Substrates


Quantity
  OR


Model : CM-8825FN

Coating thickness meter conquers the difficulties of
non-destructive measuring of coating thickness on both magnetic and non-magnetic base that can be used on many applications even on applications that require greater precision. It is the most advanced and top quality rugged meter   that   uses magnetic induction and eddy current principle to measure thickness of magnetic coating on nonmagnetic base as well as nonmagnetic coating on magnetic base.Lightweight and equipped with   BUILT-IN F & NF probes   it carries out   high-speed and   accurate results on either single or continuous measuring mode and covering   wide range of
0~1250um or 0~50mil .

The  F probe   (Magnetic Induction) measures the thicknessof   non-magneticcoating layers on magnetic substrate.   Examplesof non-magnetic coating layer :   aluminum,chrome, copper, enamel, rubber, lacquer, dye, powder,varnish & paint. Other coating layers are the following: galvanizinglayer, lacquer layer, porcelain enamel layer, phosphidelayer, copper tile, aluminium tile, some alloy tile,paper .   Samples of magnetic substrate are the following: steel, iron, nickel, alloy and magneticstainless steel.

While  NF probe   (Eddy Current) measures the thicknessof   non conductive coating layers on non-ferrous substrate. Examples of nonconductive   coatinglayer :enamel, rubber, paint, varnish, plastic anodic-oxidelayer.   Samples of Nonferrous substrate   arethe following: aluminum, brass, zinc, tin and nonmagneticstainless steel.

In addition we keep in mind that the safety of the user should always comes first and so we made sure that our products   comply with all the health and safety required standards set by the European Directives   as well as   passing   both ISO-2178 and ISO-2360, DIN, ASTM and BS set standards.



Features:

  • With Built-in F & NF probe for a wireless operation
  • Capable to measure magnetic & nonmagnetic materials in high resolution and wide measuring range of 0~1250um or 0~50mil
  • Has CE marking, conforms with the essential health and safety requirements set out by the European Directives
  • Conforms and passed the standards of international standards including ASTM, DIN, BSandISO-2178 aswell as ISO-2360
  • Light weight and provides Single-handed menu navigation
  • With automatic substrate recognition
  • Provides Single & Continuous measurement mode with Metric/English conversion
  • With manual and automatic shut down
  • Features instant results that's clearly & legibly shown on an easy-to-read LCD screen and gives exact reading with no guessing or errors
  • Suitable for the laboratory, Powder Coating Companies,Manufacturing Companies, Paint Suppliers,Manufacturing Companies, Steel and Aluminum Refinishing, Automobile Dealers, Auto Auctions,Body Shops, Auto Detailers and any company needing a highly accurate measurement of the dry coating thickness and can be used even in harsh field conditions
  • Durable,long lasting components with a strong &light weight ABS plastic housing assures maintenance free



Specification:

  • Probes : Built-in F probe & NF probe
  • Operating Principle : magnetic induction and eddy current(F & NF)
  • Measuring Range : 0~1250um/0~50mil
  • Resolution : 0.1um (0~99.9um) , 1um (over 100um)
  • Accuracy : ±1-3%n or ±2.5um or 0.1mil(which ever is greater)
  • Measuring Area : 6mm
  • Min.Sample Thickness : 0.3mm
  • Modes : Single & Continuous
  • BatteryIndicator : low battery indicator
  • Metric/Imperial : convertible
  • Power supply : 4 x 1.5V AAA(UM-4)battery
  • Manual or Auto power off
  • Operating Conditions: 0~50°C(32°F-104°F) Temperature, <80% Humidity
  • Dimensions : 126mm x 65mm x 27mm
  • weight : 81g (not including battery)



Set Includes:

  • 1 x Coating Thickness Meter
  • 4 x Calibration foils
  • Aluminum& Iron substrates
  • English User's Manual
  • Protective Carrying Case with Shock absorbent contoured rubber inside



Optional Item  ( not included in set)

          Please click here to buy this optional item  CD (software) and cable on extra.
or you may contact us at sales(at)gainexpress.com if you want an optional items to be included in your order
